controllers and thermostats
HWTH1 HORIZONTAL
Programmable horizontal touchscreen thermostat for under-floor heating systems. Features a real-time clock for precise program timing, individual-day or full-week scheduling, multi-mode sensor settings, frost protection, keypad lock, and easy horizontal flush-mount installation.
Key Features
Real-Time Clock & Day Setting
Touch-to-set clock and weekday ensure your heating programs start on time.
Customizable Scheduling
Program individual days or all seven at once, with default Wake/Leave/Return/Sleep events.
Flexible Sensor Modes & Safety
Select Air-only (A), Air+Floor (AF) or Floor-only (F) sensing; adjust switching differential; engage frost protection and keypad lock.
| Specification | Details |
|---|---|
| Model Number | HWTH Horizontal Thermostat |
| Orientation | Horizontal flush-mount installation |
| Real-Time Clock | Touch-to-set clock & day-of-week |
| Programming Options | Individual-day or 7-day programming |
| Default Schedule |
• Wake (07:00 – 22 °C) • Leave (09:30 – 16 °C) • Return (16:30 – 22 °C) • Sleep (22:30 – 16 °C) |
| Sensor Modes | Air-only (A), Air+Floor (AF), Floor-only (F) |
| Switching Differential | Adjustable 1–10 °C (default 1 °C) |
| Frost Protection | Built-in frost protection with manual on/off |
| Keypad Lock | Lock/unlock screen with 5-second press |
| Manual | Download Horizontal Thermostat Manual (PDF) |
